Will adding a crossover filter create better phase alignment between speakers from different families?

By Nathan Lively

In an ideal world, we would always use matching speaker sets. Main from brand A is designed to work with Sub from brand A and we have confidence that when they are deployed in the field that they will work harmoniously together.

But what happens when we combine two speakers from different families or brands?

Takeaway

If phase slopes do not match, look for differences in phase divisible by 45 to identify filter opportunities.

Seeing actionable data in our audio analyzer for the main to subwoofer crossover frequency range is like seeing a shooting star. It’s rare and it never happens when someone else is looking.

Sometimes we get lucky and they match up pretty well.

VRX918SP
t4

For example, a dB Technologies DVA T4 would normally be matched with something from the same family like a DVA S1518N subwoofer. But if there are no more S1518N available at the sound company, they may send a substitute. This exact situation happened to me and they sent a VRX918SP. I had not used one in a long time and I wondered, will they work together?

Luckily, they did.

T4 + VRX918SP
T4 in red, 918 in blue, summation in pink

Anecdotally, I would say that 60% of the time, it works every time. You get lucky and they play together out of the box. So what do you do the other 40% of the time?

What if you go through your normal alignment process and you end up with something like this.

milo+650p w3.66ms
Milo + 650p w/3.66ms

I know, I know. Not the most dramatic example, but here we have a main+sub pair that will not achieve maximum summation through the crossover region. You could try a polarity inversion and different delay values, but no matter how much you fiddle with it, you won’t be able to grab that last 5%.

You might start wishing you were an expert at all-pass filters, but then you realize that your DSP doesn’t even have them. You start wondering if maybe adding a filter would produce better alignment.

To help satisfy your curiosity here’s a helpful rule to memorize: every order * 45º = total phase shift.

crossover over
I’m too lazy to label them all.

In practice, if you compare two phase measurements and observe phase shift of 45º, 90º, 135º or any multiple of 45º, consider adding a filter.

In the example we started with above, it looks like we might need to add a filter to red Sub trace. After all, it needs to be 45º more steep, right?

Not so fast. The measurement is misleading because I added 3.66ms to the sub measurement in pursuit of alignment. Let’s remove the delay first. I’ll also add a few milliseconds to the delay locator to unwrap the phase and make it easier to look at.

unwrap phase

From this graph we can identify a couple of things:

  1. The red Main trace is steeper than the blue Sub trace.
  2. They are 90º apart at 72Hz and 180º apart at 190Hz.

90 / 45 = 2

This makes me think that a 2nd order filter may work. The image below of a 2nd order (12dB/oct) Butterworth filter shows both the magnitude and the phase. You can see 90º of phase shift at 72Hz sloping down to 150º at 190Hz.

Let’s insert it and see the result.

The slopes of the phase traces are now better matched (without electronic delay) and I have reduced the crossover interaction from 2oct to 1oct.

Now that we have a relative preset, let’s deploy these speakers and see how easy it is to restore alignment with a simple distance measurement.

room design

If we did nothing. The prediction would look like this.

It looks like we have put the audience into a null while our precious summation blasts into the sky.

Here’s the magnitude at the measurement mic location.

measurement mic null

Let’s see if we can fix that.

  1. Distance to main = 22ft
  2. Distance to sub = 18.7ft
  3. 22 – 18.7 = 3.3
  4. 3.3 * 0.9 = 2.97ms in the Sub output
deployed

Wait, it didn’t work. What happened? Why is there still 180º of phase difference between main and sub??

Let’s check to see if I applied any extra processing.

This u-shaping filter says that it’s only applying 30º of phase shift, but our results argue otherwise. There may be another detail I’m missing here, but I think a polarity inversion in the Sub will fix it.

deployed aligned

Better!

And here’s the final measurement of combined systems.

And we have pushed the coupling zone down onto the audience.

Big thanks to Mauricio Ramirez for the feedback! [why is there no luchador emoji??]

What about you? Have you tried improving alignments by adding crossover filters? What were your results?

Further questions

Mystery polarity inversion?

I discovered later that if I turn the delay integration (Lyon 55-70, not sure if that matters) on and back off again, the polarity inversion from the u-shaping filters disappears.

Why not just compare magnitude slopes instead of phase?

I thought about this, but the more I looked into it, the more confused I got. Measuring electrical filters makes pretty pictures that are easy to compare, but real speakers measured in the field are more difficult to compare.

Here’s an example speaker pair. Do the slopes match?

Looking at the phase graph, it seems clear, but I’m not so sure about the magnitude graph. Where should I start counting dB/oct and where should I stop? The red trace has a nice steady slope that looks like 24dB/oct, but the blue trace looks almost asymmetrical since it has a gradual slope and then a sudden drop-off. 🤷‍♂️

Loved this post? Try these:
  1. 3 Phase Alignment Hacks to Make Your Sound System Tuning Easier
  2. How to flatten the phase for easier main+sub alignment
  3. Smaart® Beta: Will the new filter control in the delay finder help with your main+sub alignment?

Get My Top 5 Posts

about mixing and sound system tuning

I respect your privacy. I will never share your email address with anyone, period.


Smaart® and the Smaart logo are registered trademarks of Rational Acoustics LLC and are not affiliated with Nathan Lively or Sound Design Live.

Comments

  1. Peter says

    May 9, 2020 at 14:56

    Nathan
    The sub falls off with less then 12dB. If I remember correctly from your video on crossfreqency you want a 12 dB + an 12 dB LR to get a 24 dB as a result.
    If you follow that route would the phase align then be the same and did you use the same correction.

    Reply
    • Nathan Lively says

      May 9, 2020 at 18:05

      Hey Peter, it’s a good point. Wouldn’t it be easier to just look at the magnitude response and roll-off? The math would be easier.
      I did consider this, but unfortunately, I could not get it to work reliably on field measurements. On electrical measurements of filters, it’s easy, but data from rooms is highly variable and noisy. Where is 0dB? Is the slope 20dB/oct or 24dB/oct? I really had a hard time figuring it out. There might still be a way to do it, with enough practice, but it just seemed like comparing phase was more reliable.

      Reply
  2. Sohel Dantes says

    May 12, 2020 at 12:05

    3.3 * 0.9 = 2.97ms in the Sub output

    Could you please explain derivation of 0.9 and why it is multiplied. (Im pretty sure im forgetting some very basic Math)

    Reply
    • Nathan Lively says

      May 12, 2020 at 14:03

      Hey Sohel, 0.9ms/ft is an estimation for the speed of sound. This may also help – http://www.sounddesignlive.com/how-to-estimate-delay-and-level-offset-between-speakers-in-your-3d-models/

      Reply
  3. Sunil Karanjikar says

    May 26, 2020 at 19:29

    Hey Nathan,
    I assume you did all of this is MAPP XT. Are you using 2 mic/probe locations for this process? It wouldn’t make sense that the simulator shows good phase overlap but then also shows a drop in the magnitude response for the same mic/probe location.

    Reply
    • Nathan Lively says

      May 28, 2020 at 14:02

      Hi Sunil!

      >I assume you did all of this is MAPP XT.
      Correct.

      >Are you using 2 mic/probe locations for this process?
      No. Single location.

      >It wouldn’t make sense that the simulator shows good phase overlap but then also shows a drop in the magnitude response for the same mic/probe location.
      I don’t understand, but I’d like to. Maybe you could draw on some of the images from the article or even edit the MAPP design?

      Reply
  4. D. White says

    September 27, 2020 at 08:12

    I’m looking for the crossover phase equations. Many sites overlook the phase, which, as you point out, can lead to bad results.

    You are discussing the phase. I would like to read this article, but none of the pictures show up on my tablet. I’m using the Brave browser on my Samsung tablet (Android 7.1.1). Brave is a slimmed down browser based on Chrome.

    Reply
    • Nathan Lively says

      September 28, 2020 at 14:11

      Hi D. I’m not sure if this is what you are looking for, but maybe…
      https://www.merlijnvanveen.nl/en/study-hall/165-group-delay-101

      > none of the pictures show up on my tablet
      Shoot. That sucks. I’m not sure why. Would you be able to send me a screen shot of the problem? Also, what happens if you use a different browser?

      Reply
  5. D. White says

    October 2, 2020 at 10:55

    Hi Nathan
    I tried Chrome and Firefox and still no pictures. The text is there with blank white spaces where the pictures should be. If I press and hold in the center of one of these spaces to get the options, it shows a yH5BAEAAAAALAAAAAABAAEAAAIBRAA7.bin filename. I tried opening the file in another tab and got this:


    I’m not sure how to attach a screenshot.

    Reply
    • Nathan Lively says

      October 2, 2020 at 14:12

      Hey D., thanks for alerting me to the problem. I’m looking into it.

      Reply
      • Nathan Lively says

        October 2, 2020 at 15:00

        Ok, I think the problem has been fixed. Please let me know.

        Reply
  6. D. White says

    October 4, 2020 at 21:13

    It works great now. I can see all of the pictures and graphs in Brave browser. Since Brave is based on Chrome, the pics should also show up in Chrome. If I find any problems I’ll let you know. Thanks! Lots of info in the graphs to check out.

    Reply
